SS316WORKS offers stainless steel welded round pipes and tubes for pharmaceutical, food-processing, dairy, beverage, chemical, water-treatment, architectural and general engineering applications. The range includes ASTM A312 welded pipes in Schedule 10S, 40S and 80S, ASTM A269 process tubes and ASTM A554 structural and decorative tubes. Multiple stainless steel grades, outside diameters, wall thicknesses, lengths and surface finishes can be offered according to customer requirements and technical feasibility.
Stainless Steel Welded Round Pipes and Tubes
SS316WORKS supplies stainless steel welded round pipes and tubes for industrial piping, process equipment, pharmaceutical machinery, food-processing systems, dairy plants, water-treatment systems, structural fabrication and architectural applications.
Our range covers pressure and process pipes, industrial tubes and decorative or structural round tubes manufactured according to applicable ASTM specifications. Customers can select the required material grade, outside diameter, pipe schedule, wall thickness, length and surface finish according to their application.
Product Range
• Stainless Steel Welded Round Pipes
• Stainless Steel Process Tubes
• Stainless Steel Industrial Round Tubes
• Stainless Steel Structural Tubes
• Stainless Steel Decorative Tubes
• Schedule 10S, Schedule 40S and Schedule 80S pipes
• Metric and imperial dimensions
• Standard and customized lengths
• Polished, brushed and pickled finishes
Applicable Product Standards
ASTM A312
Applicable to stainless steel welded round pipes used for industrial piping and process applications. Pipes can be offered in Schedule 10S, Schedule 40S and Schedule 80S, subject to size and grade availability.
ASTM A269
Applicable to welded stainless steel tubes used in general service, process systems, heat-transfer equipment and other industrial applications.
ASTM A554
Applicable to welded stainless steel mechanical, structural, architectural and decorative tubing.
Indicative Size Range
Welded Round Pipes:
• Nominal Bore: 8 mm to 100 mm
• Nominal Pipe Size: Approximately 1/4 inch to 4 inches
• Outside Diameter: Approximately 13.72 mm to 114.30 mm
• Available Schedules: 10S, 40S and 80S, subject to size availability
Welded Round Tubes:
• Outside Diameter: Approximately 12.70 mm to 127 mm
• Wall Thickness: Approximately 1 mm to 8 mm
• Standard Length: Up to 6000 mm
• Customized and intermediate dimensions may be offered subject to technical feasibility
Available Material Grades
• SS304
• SS304L
• SS316L
• SS316Ti
• SS321
• SS301LN
• SS202
• Duplex 2101
• Duplex 2205
• Super Duplex 2507
• SS409M
• Other stainless steel grades on request
The availability of a particular grade, size, schedule and wall-thickness combination is subject to technical and commercial confirmation.
Supply Conditions
For applicable ASTM A312 and ASTM A269 requirements, pipes and tubes may be offered in annealed and pickled condition with hydrostatic testing and relevant inspection documents.
Structural and decorative tubes under ASTM A554 can be supplied in mill, brushed or polished surface conditions.
Available Surface Finishes
• Mill finish
• Annealed and pickled finish
• Brushed finish
• Mirror finish
• 180-grit polished
• 220-grit polished
• 320-grit polished
• 400-grit polished
• 600-grit polished
• 800-grit polished
• Customized surface finish on request
Key Features
• Excellent corrosion resistance
• Consistent outside diameter and wall thickness
• Suitable for welding and fabrication
• Multiple grades and schedules
• Smooth internal and external surfaces
• Suitable for process and structural applications
• Metric and imperial sizes
• Multiple polishing options
• Custom lengths subject to feasibility
Applications
• Pharmaceutical process equipment
• Food-processing plants
• Dairy and beverage systems
• Chemical process piping
• Water-treatment systems
• Heat exchangers
• Industrial machinery
• Structural frames
• Architectural fabrication
• Railings and decorative structures
• Commercial kitchen equipment
• Oil, gas and utility piping
• General engineering fabrication
Inspection and Documentation
Applicable supplies may be provided with a Mill Test Certificate or Inspection Certificate as per EN 10204 3.1. EN 10204 3.2 certification, special testing and third-party inspection are subject to prior confirmation.
Information Required for Quotation
Please share:
• Required material grade
• Pipe or tube specification
• Applicable ASTM standard
• Outside diameter or nominal bore
• Pipe schedule or wall thickness
• Required length
• Surface finish
• Quantity
• Testing and certification requirements
• Delivery location
Contact SS316WORKS
For stainless steel welded round pipes and tubes, please share your complete technical requirement with SS316WORKS for availability confirmation and a competitive quotation.
Email: ss316works@gmail.com
Website: www.ss316works.com
Phone: +91 8949369649
